| Three-phase induction motors with cast iron IE4 | |||||||
| 37 to 200 kW | |||||||
| Developed to reduce drastically the energy consumption of the machines | |||||||
| while maintaining maximum level of robustness and performance, | |||||||
| the new Super Premium IE4 cast iron CILS series is integrating the global IMfinity® range. | |||||||
| The IMfinity® CILS is compliant to the ecodesign requirement of the EU 2009/125/EC | |||||||
| directive and to the latest stage of the Commission Regulation UE 2019/1781 | |||||||
| on induction electric motors starting July 2023. Indeed, from this date, | |||||||
| electric motors with a power between 37 kW and 200 kW and covered by the regulation | |||||||
| must have an energy efficiency level of IE4 minimum. | |||||||
| The CILS, cast iron 3-phase induction motor is a general-purpose range designed for industrial | |||||||||
| applications to offer robustness, IE4 energy efficiency and flexibility of mounting. | |||||||||
| The CILS series is mainly oriented on Fan, Pump and Compressor applications, | |||||||||
| while benefiting from the great expertise of Nidec Leroy-Somer in developing reliable, powerful and adaptable motors. | |||||||||
| Advantages | |||||||||
| High reliability | |||||||||
| Fixed or variable speed | |||||||||
| Energy efficiency: IE4 efficiency level | |||||||||
| Compliant to most international standards | |||||||||
| Easy commissioning & maintenance | |||||||||
| Power supply frequency | Hz | 50 |
| Frame size | mm | 225 – 315 |
| Ingress protection | IP | 55 |
| Number of poles | 2, 4 | |
| Power | kW | 37 to 200 |
| Voltage | V | 400 |
| Shaft type | steel |
